Coating Machine

Standard Features

Krishna Engineering Works India, a leading manufacturer, exporter and supplier of Coating Machine from last 25 years. High quality Coating Machine available with different types of range.

Heavy duty side M.S. steel walls to ensure vibration free running at high speed.
Foundation free base frame.
High velocity air blower for fast dying.
Good quality electronic input drives, motors, Tension Control System etc.
All free rollers are dynamically balanced.
Pneumatic functions for impression rolls.
Auto tension control.
Auto web aligner.
Careful quality control in manufacturing process to ensure years of maintenance free running.

Range of Coating Machines Like:

Silicon
Platinum
Gum Coating for sticker sheet
Paper
VMCH
PVDC
Pilot
DG

Technical Specification

Working Speed	140 M/min to 200 m/min
Max. Web width	600 / 800 / 1000 / 1200 mm
Unwind Roll Dai.	600 / 800 mm
Rewind Roll Dai.	600 / 800 mm
Drying Section	Multi-zone arch type
Heat Source	Electrical / Hot Air
Coating Section	Gravure / Reverse Roll
Laminating Section	Chilling / Heating Roller with Pneumatic Nip Roll
Drive	Variable Speed: DC/AC
Unwind / Rewind	Simplex / Duplex

Effective Laminating Width	500mm ~ 3600mm
Max. Laminating Speed	100 ~ 150mpm
Max. Mechanical Speed	150m/min.
Diameter of Unwind / rewind	0800mm
Diameter of roll core	076mm
Coating Layer quantity	Two Layers (Once)
Drying Source	Electric / Thermic Fluid/ Diesel Hot Air System
Construction	Ribbed Anti Vibration Cast Iron (C.I.) Body.
